Petal Type LED Surgical Light for Modern Operating Rooms

Introduction

LED surgical lights are essential equipment in modern operating rooms. Their design must meet strict medical requirements, including high brightness, shadow-free illumination, cold light sources, and reliable performance. As surgical technology continues to advance, hospitals require more precise and efficient lighting solutions to support complex medical procedures.

Yikun Medical is committed to continuous innovation in medical equipment. By combining advanced lighting technology with ergonomic design, we provide high-quality surgical lighting systems that improve both surgical visibility and operating room safety.

High-Density Mixed Light Technology

This petal-type LED surgical light adopts high-density mixed light technology, using multiple LED modules arranged in a petal-shaped structure. The multi-light-source design creates a more uniform illumination field and effectively reduces shadows caused by surgeons’ movements during operations.

The advanced LED system provides stable lighting with excellent color rendering, ensuring that surgeons can clearly identify tissues, blood vessels, and anatomical structures during procedures.

Adjustable Brightness and Color Temperature

The surgical light supports 10 levels of brightness adjustment, allowing surgeons to select the most suitable illumination for different procedures.

The illumination range is 40,000 – 160,000 lux, providing strong and stable lighting for various surgical applications.

The lamp also offers three adjustable color temperature levels (3500K–5000K ±300K), which helps improve tissue contrast and visual clarity. Surgeons can choose different lighting environments according to surgical requirements.

In addition, the spot diameter can be adjusted between 120 mm and 300 mm, ensuring flexible illumination coverage for both small and large surgical fields.

ENDO Mode for Endoscopic Surgery

The integrated ENDO mode is specially designed for endoscopic procedures. It reduces glare and reflection from surgical instruments and monitors, providing a more comfortable visual environment for minimally invasive surgeries.

This function makes the surgical light suitable not only for traditional open surgeries but also for advanced endoscopic procedures.

Efficient Heat Dissipation Design

To ensure stable performance and longer service life, the lamp head uses a precision-cast high thermal conductivity aluminum alloy structure.

The enlarged internal heat dissipation area allows heat generated by the LED modules to be quickly released. Combined with energy-efficient LED technology, this design effectively reduces the operating temperature of the lamp and improves durability.

Sterilizable Handle for Easy Operation

The surgical light is equipped with a removable sterile handle, which can be sterilized at 121°C using high-pressure steam sterilization.

This allows surgeons and operating room staff to easily adjust the position, angle, and depth of the lighting during surgery while maintaining strict sterile conditions.

Aerodynamic Lamp Design

The streamlined lamp body design improves airflow circulation in the operating room. This aerodynamic structure helps reduce the accumulation of dust and bacteria around the lamp head, contributing to a cleaner surgical environment.

Advantages of LED Surgical Lighting

Compared with traditional halogen surgical lights, LED surgical lights provide several important advantages:

Lower heat generation

No infrared (IR) radiation

No ultraviolet (UV) radiation

Longer service life

Higher energy efficiency

More stable illumination

These features make LED surgical lights safer, more environmentally friendly, and more reliable for long-term hospital use.

Nantong Yikun Medical – Advanced Medical Equipment for Safer and Brighter Surgeries.

Please contact us if you have any needs.

www.nantongmedical.com.cn

Contact person:Muriel

Email:muriel@nantongmedical.com
